STE0805MW75R250F,WALTER,Metal Current Sensing Chip Resistor

STE0805MW75R250F

Metal Current Sensing Chip Resistor ,0805 ,0.25R(250mR) ,±1% ,3/4W(0.75W) ,MnCu ,±50PPM

✖

The image is for reference only, please refer to the drawing for details

Company Profile： Walter_ Profile_JAP.pdf

Expand

Walter_ Profile_JAP.pdf
Walter Profile-CN-2026.pdf
Walter_ Profile_ENG.pdf

Data Sheet： STE-C-series.pdf

Electronic： Walter_POWER_Fuses.pdf

Expand

Walter_POWER_Fuses.pdf
Walter_Components_Catalog.pdf
Walter_ Product_overview.pdf

RoHs Report： CSR_RoHS.pdf

Expand

CSR_RoHS.pdf
CSR-Series REACH-224.pdf

REACH Report： WALTER_REACH240

Product number：	R09-0805-R250F1QM11JSTE0
Manufacturer Product Number：	STE0805MW75R250F
Manufacturer ：	WALTER
Series ：	WALTER-STE-C
Type ：	Metal Current Sensing Chip Resistor
Size ：	0805
Resistance Value ：	0.25Ω(250mR)
Resistance Tolerance ：	±1%
TCR(ppm) ：	±50PPM
Resistance Power ：	3/4W(0.75W)
Description：	Metal Current Sensing Chip Resistor ,0805 ,0.25R(250mR) ,±1% ,3/4W(0.75W) ,MnCu ,±50PPM

Series Introduce Find Similar

Attribute Name	Attribute Value
Product Series	STE-C-series
Size (in)	0603~4527
Resistance（mΩ）	2~700mΩ
Resistance Tolerance	±0.5%(D) / ±1%(F)
Power Rating	0.5~4.0W
Material	NiCu alloy
Substrate	Alumina Ceramic
Adhesion layer	Epoxy
Resistive element	Cu alloy
Terminal electrode	Cu / Ni / Sn
Protective coating	Flame-retardant epoxy
Marking coating	Flame-retardant epoxy
Operating Temperature	-55℃～170℃
Storage Conditions	10℃~40℃
Preheating	145 ± 15℃, max. 120 sec
Soldering	min. 220℃, max. 60 sec.
Maximum temperature	260±5℃, max. 10sec.
Rework Temperature （hot air equipment）	350℃,3~5seconds
Termination Style	SMD

Series Introduce Find Similar

STE0805CW75R250F

Metal Current Sensing Chip Resistor ,0805 ,0.25Ω(250mR) ,±1% ,3/4W(0.75W) ,NiCu ,±50PPM ,WALTER-STE

$0.032206 More

File

File Type	File Name
Company Profile	Walter_ Profile_JAP.pdf
	Walter Profile-CN-2026.pdf
	Walter_ Profile_ENG.pdf
Data Sheet	STE-C-series.pdf
Electronic	Walter_POWER_Fuses.pdf
	Walter_Components_Catalog.pdf
	Walter_ Product_overview.pdf
RoHs Report	CSR_RoHS.pdf
	CSR-Series REACH-224.pdf
REACH Report	WALTER_REACH240

Lead time： Estimated delivery date 2026-11-06
